Appendix F: Controller LED and I2C Connector Quick Reference ● 127
J1:
● Adaptec RAID 2405/2405Q I2C Board Connector : Molex 22-43-6030 or equivalent
● I2C Mating Cable Connector: Molex 22-43-3030 or equivalent
J4:
J1 Pin Number Signal Description
2 ACTIVITY LED Cathode
1 +3.3V LED Anode
J4 Pin Number Signal
3I2C Clock
2Ground
1I2C Data
