© ADB bvba All Rights Reserved 25
3.0 Parts
3.1 Order Codes
3.1.1 Spare Parts List Table 8: RGL Spare Parts
Ordering Code
1,4
44A4744-
Power
1 = Mode 1, Current-Driven (ETL Certifi ed)
6
2 = Mode 2, Voltage-Driven, 120 VAC (ETL Certifi ed)
3 = Mode 2, Voltage-Driven, 220-240 VAC
(ETL Certifi ed)
4 = Direct Lamp Access, Current-Driven
Remote Monitor Feature
1 = Non-monitored (ETL Certifi ed)
2 = Monitored (ETL Certifi ed)
5
Lens
1 = Traffi c Signal Yellow (ETL Certifi ed)
2 = Traffi c Signal Red
3
3 = ICAO Yellow
2
4 = Red/Green
3
Photocell Feature
1 = Without photocell, Mode 1 only (ETL Certifi ed)
2 = With photocell, Mode 2 only (ETL Certifi ed)
Notes
1
Runway Guard Lights should only be powered with
ferroresonant type CCRs and not with thyristor type CCRs
2
Complies with color and illumination of ICAO Annex 14, Vol. 1,
6th edition specifi cations for Runway Guard Lights. ICAO L-804
uses 150 W, 6.6 A lamps.
3
Color not recognized by the FAA
4
1832RGL base plate is ordered and shipped separately. See
data sheet 2012 for more details.
5
Not available in direct lamp access version. Monitoring, if
needed, is provided by externally connected equipment.
6
The L-804 halogen, current powered, 50 Hz, non-monitored,
ICAO yellow fi xture (Part No. 44A4744-1131) carries the CE
Mark.
Description Part No.
Base plate, L-867B heavy-duty 1832RGL
Canopy, FAA 60A2408
Canopy, ICAO 60A2408-1S
Canopy brackets 60A2410
Frangible column, 2 - 11.5 TPI (Used with 1832RGL) 60A2398
Frangible coupling, 11 TPI threaded (Normally used in metric
applications. Not for use with 1832RGL base plate)
60A2398-1
Gasket, lens 63A1109
Lamp, 100 W/6.6 A, Pk30d (FAA) 44B1643
Lamp, 150 W/6.6 A, Pk30d (ICAO) 48A0353
Lens, ICAO yellow 63A0930-2
Lens, traffic signal red 63A0930-1
Lens, traffic signal yellow 63A0930
PCB, current-driven 44A6122-C
PCB, voltage-driven 44A6122-V
Photocell (120 V) 48A0089
Photocell (240 V) 48A0089-240
Photocell socket 49A0095
Retrofit kit (to replace 44A4771 PCB with 44A6122-C) 94A0333
