MIKADO USER MANUAL
User Manual - page 4 www.adblighting.com
Issue 1.0
Note: all connections should be made with the power turned off, otherwise functioning may
be affected and can even damage the equipment under certain conditions.
1.4 Power Supply
As all equipment used in computer systems, your system is sensitive to the characteristics of
the network and in particular to variations and voltage peaks.
Consequently, we advise you to use an appropriate line conditioner on this equipment.
Please consult us if you are in any doubt about this.
The line is to be protected by fuse or by circuit breakers and is to be provided with an earth
connection for personal safety.
Important Notice for Power Cables
Power cables and connectors are an important part of your equipment and contribute to its
safety.
Always use the connector to make or interrupt the link; never pull on the cable.
Do not damage the cable or the connectors in any way; do not pinch or tie together power
supply and signal cables, check them at each installation and at regular intervals on a
permanent installation.
1.5 Electrical Connection
TO PREVENT THE RISK OF ELECTRIC SHOCK, DO NOT OPEN THE DESK.
THERE ARE NO USER SERVICEABLE PARTS WITHIN. REFER SERVICING TO
QUALIFIED ENGINEERS ONLY. LETHAL VOLTAGES ARE PRESENT INSIDE!
ALWAYS DISCONNECT FROM THE POWER SUPPLY BEFORE OPENING FOR
INSPECTION.
MIKADO is a professional lighting control systems developed with simplicity of use in mind.
In order to maintain the proficiency of the built in safety features, this equipment shall be
installed and maintained by qualified service personnel only.
1.6 FEATURES
• 12 faders in 2 preset operation or 24 faders in wide preset operation, each with own
flash button and indicator LED.
• 3 pages of memory with 12 submaster faders on each page - 36 total memories.
• Each Submaster can be either a Memory or Chaser and up to 13 memories/Chasers
can run concurrently.
• Three Preset Masters – A preset master, B preset master and Grab master.
• Add/Solo button with flash level Master.
• Edit and Preview of stored memories with channel level indicators.
• Memory fade times from 0 - 30 secs.
• Chaser dipless crossfade rate from 0 - 100%.
• Speed adjustment of Chaser steps 0 - 999BPM.
• Chaser effects including Start/Stop/Step, random, bounce, single shot, forward
direction, reverse direction, delete step and add step.
• Audio Input with Bass step effect for Chasers with audio level adjustment.
• ¼" mono jack for connecting footswitches to remotely advance Chaser sequences.
• DMX512-A output on 5 pin XLR connector.
• Integral fused power supply - input range of 190-260V AC, 47 -65Hz.
110VAC models available.
• Compact – 440 mm (w) x 352 mm (d) x 90 mm (h).
