113687-3 21
6 MAINTENANCE
Only qualified personnel should maintain this equipment.
6.1 Electrical and mechanical troubleshooting
Before calling the Technical Service Center, check the
following:
that power is supplied to the machine.
the condition of the fuses.
that the voltage is correct for the machine.
If the washer extractor fails to obtain the required
level of water, check:
that the water mains tap is open.
that the water inlet filter is not blocked.
that the water pressure is between 2 and 4 kg/cm
2
(28
and 56 psi).
If the washer extractor vibrates excessively, check:
None of the panel screws are loose.
If a power cut occurs, check:
The tub is drained and the door is blocked. If you want
to take the clothes out of the washer extractor, unlock
the door by pulling down the belt located behind the
front panel.
6.2 Error messages
On the washer extractor screen, warning or fault
messages may be displayed during or after the
execution of a wash program. Except in the event of a
power cut, the washer extractor will be paused (drain
pipe off, motor off, etc.) awaiting user action.
Message Possible causes Action
PWR FAUL
UAIT
This message appears on recovering the power after having been cut-off.
If the power cut occurs during the spin cycle, the message "WAIT" is
displayed. For safety reasons, wait approximately 1.5 minutes without
pressing anything until "PWR FAULT" is displayed.
Press START: the program continues to
operate in the same cycle as before the power
cut.
Press ESC: the program ends.
E2
FAULT LOCK
This message appears when it is detected that the door can not be unlocked
at the end of the program or that it has unlocked during the program.
Press ESC: the program ends.
E3
FAULT DRAIN PIPE
This message is displayed when, in spite of deactivating the emptying valve
output, the water level inside the drum has not decreased for a pre-
established period of time.
Press START: the program continues.
Press ESC: the program ends.
E4
FAULT WATER INLET
This message appears when, in spite of activating the corresponding
solenoid valves' outputs, the water level inside the tub has not increased
during a certain pre-established period of time.
Press START: the program continues.
Press ESC: the program ends.
E5
HEATING FAULT
This message is shown when, in spite of activating the heating output, the
water temperature has not increased for a certain pre-established period of
time.
Press START: the program continues.
Press ESC: the program ends.
E6
MAX. TEMP
This message is displayed when the water temperature has exceeded 95 ºC.
Press START: the program continues.
Press ESC: the program ends.
E7
THERMOSTAT OPEN
This message appears when the water temperature exceeds 203ºF.
Press START: the program continues.
Press ESC: the program ends.
E9
MOTOR HEATING
This message appears when the thermal protection of the washer extractor
motor is detected to have not been activated.
Press START: the program continues.
Press ESC: the program ends.
E10
UNBALANCE
This message appears when the final spin activates the unbalance micro
three times.
Press ESC: the program ends.
E11
CLOTHES HOT
This message is displayed when a program finishes but the water
temperature inside the tub exceeds 122ºF.
Press ESC: the program ends.
E12
WATER IN TUB
This message is displayed when a program execution is finished but there is
still water inside the tub. The door can not be opened until the water is
drained from the tub.
Press ESC: the program ends.
If the washer extractor is set to COIN MODE or CP MODE, the door will unlock, after the safety time has elapsed, in
the event of the following errors: PWR FAUL, E2, E9
