B. STEAM MODELS (ADS-464)
NOTE: ADC reserves the right to make changes in specifications at any time, without notice or
obligation.
* Size of piping to dryer varies with installation conditions. Contact factory for assistance.
MAXIMUM CAPACITY (D RY W EIGHT ) 460 lbs.
209.09 kg
TOTAL WEIGHT 11,000 lbs.
4,949.6 kg
TOTAL SHIPPING WEIGHT (
STRETCH WRAP / SKID ) 11,162 lbs.
5,063.08 kg
TILT HEIGHT 137-1/4"
348.6 cm
OPERATING HEIGHT 114-1/2"
290.83 cm
FULL TILT DEPTH 117-1/2"
298.45 cm
OPERATING DEPTH 95"
241.3 cm
WIDTH 122"
309.88 cm
TILT LOAD (
REAR TILT ) 15º
TILT UNLOAD (
FRONT TILT ) 15º
UNLOADING HEIGHT FROM FLOOR 43-3/4"
111.12 cm
LOADING HEIGHT FROM FLOOR 65-5/8"
166.69 cm
DOOR OPENING 53-1/4" x 49"
135.26 cm x 124.46 cm
BASKET DIAMETER 69-1/8"
175.58 cm
BASKET DEPTH 80-5/16"
203.99 cm
BASKET VOLUME 175 cu. ft.
4.96 cu. m
MINIMUM LOAD SIZE 250 lbs.
113.64 kg
MAXIMUM LOAD SIZE 460lbs.
209.09 kg
BOILER HORSEPOWER 60 Bhp
STEAM INLET CONNECTION SIZE* 2-1/2" N.P.T.
-
STEAM RETURN CONNECTION SIZE (2 PLACES )1 1/4" N.P.T.
-
BASKET MOTORS (2 MOTORS )
(2) 5 HP
(2) 3.73 kw
BLOWER MOTOR
25
HP
18.65 kw
BLOWER MAXIMUM AIRFLOW 13,000 cfm
368 cmm
MAXIMUM DUCT BACK PRESSURE
1.25" (
W. C. )
3.1 mbar
MINIMUM DUCT DIAMEMTER 24"
60.96 cm
COMPRESSED AIR PRESSURE REQUIRED 80 psi (±10 psi)
5.63 bar (±.7)
COMPRESSED AIR VOLUME REQUIRED 20 cf/hr
.57 cm/hr
COMPRESSED AIR CONNECTION 3/8" N.P.T.
-
Shaded areas are stated in metric equivalents
