32 American Dryer Corp. 113403-17
MACHINE INFO
Coin Vault: $0.00
Upper Hours: 0
Lower Hours: 0
Serial #: 1000000
Software: R3-3.0
PROGRAM SETUP
Dry Mode Coin / Free Dry Mode Coin Dry Mode
CONTROL
SETTINGS
Language
Multilanguage Off
Language 1 English
Language 2 French
Temp Scale °F / °C °F
Buzzer Settings
End of Cycle On
Beep Count (1 - 10)
Backlighting (0 - 200)
MACHINE
SETTINGS
Lint Cleaning Freq (1 - 3 Hours)
Axial Max Temp (100° - 180° F / 32° - 82° C)
KEY
SETTINGS
Time for Amt to Start (1 - 99 Minutes)
Time for Top Off (1 - 99 Minutes)
Dry Temp (100 - 160F)
Cool Time (0 - 9 Minutes)
Reversing Mode (Off / On)
VENDING
OPTIONS
Currency Symbol $ GBP Euro Yen Tk
Vending Mode ACC Time ACC Coin
Vending Safe Guard Bad Coin Reset / Lo
Clear Escrow (0 - 99 Minutes)
Clear Coin Vault? No / Yes
Left Coin Value ($0.01 - $25.00)
Right Coin Value ($0.01 - $25.00)
Amount to Start ($0.01 - $25.00)
Amount for Top Off ($0.01 - $25.00)
Debit Card Setup Off Gen 1 Gen 2
DIAGNOSTIC
MODE
Fault Recording Faults / Events
Diagnostic Cycle Select Cycle
Help Mode
MACHINE
SETUP
Model Gas Ele Steam Rev/Non-Rev
Dryer Type Coin / Free or OPL
Burner Setup 1, 2 Not Available on Stack
AVAILABLE
ONLY ON
REV 2.3
AND UP
Residual Moisture Control Off, On
RMC Temp (90° - 160° F / 32° - 71° C)
RMC Factor (50 - 300)
Rotation Sensor Off / On
DIAGNOSTIC MODE
FAULT
RECORDS
Upper Faults Non-Resettable
Lower Faults Non-Resettable
Events E1 - E8 Resettable
Programming _________________________
Enter Service Mode by Inserting Key and Turning Clockwise
Main Service Mode window will appear and offer 5 selections:
1: Machine Info 2: Program Setup 3: Diagnostic Mode
4: Machine Setup 5: Factory Settings
Low Key Scroll Down / Decrease Value
High Key Scroll Up / Increase Value
Med Key Accept Value or Menu Selection
Pause II Cancel Selection or Back Out of the Menu
Event Codes Defined: Top Pocket / Bottom
E1 / E4: While attempting to turn on the burner, no burner return
signal was received within RADIANT SENSOR COOL DOWN TIME.
E2 / E5: While trying to turn on burner, burner return signal received
but did not disappear within HEAT IGNITION TIMEOUT TIME.
E3 / E6: While attempting to activate the heat relay, no heat relay
contact voltage was detected. This will indicate that either the
exhaust high limit was open or that the relay is damaged.
E7: This indicates a bad coin pulse was detected on coin 1 input.
E8: This indicates a bad coin pulse was detected on coin 2 input.
E9 / EB: Upper / Lower forward pocket rotation fault count.
EA / EC: Upper / Lower reverse rotation fault count.
ED: S.A.F.E. DISABLED – Water not connected.
Factory Settings Definitions:
RADIANT TIMEOUT – During an attempt to start the burner this
parameter sets the maximum wait time for the radiant sensor to
cool and close circuit. A failure causes an E1 or E4 event and a
heat disable period specified by the HEAT DISABLE parameter
setting.
IGNITER TIMEOUT – During an attempt to start the burner this
parameter sets the maximum wait time for the radiant sensor to
heat and open circuit. A failure causes an E2 or E5 event and a
heat disable period specified by the HEAT DISABLE parameter
setting.
HEAT DISABLE – The wait time after a RADIANT or IGNITOR TIMEOUT
before another attempt to start the burner is made.
Help Codes Defined: Top Pocket / Bottom
86 / 81 Exhaust Probe Fault – Open or shorted exhaust probe.
87 / 82 Axial Probe Fault – Open or shorted axial probe.
89 / 84 Sail Switch Open Fault – Air flow failure.
88 / 83 Sail Switch Closed Fault – Sail Switch stuck or disabled.
Fault Messages Defined:
LATCHED HEAT RELAY – Heat signal present without PH8 command.
BURNER RTN VOLTAGE – Heat return signal without PH8 heat output.
ROTATION SENSOR – No tumbler rotation signal during a cycle.
EXHAUST HIGH TEMP – Exh temp 20F above highest settable temp.
BLOCKED COIN – Coin optic blocked or an open coin drop circuit.
CARD READER NO COMM – No messages received from the Gen II
card reader for 5 minutes or more.
Clear Faults:
In SERVICE MODE entering the diagnostic mode menu will clear the
operational fault. Clearing faults from the fault record is not allowed.
Clear Credit:
While machine is idle displaying “SELECT A CYCLE” press and hold
PAUSE, while holding PAUSE press HI, HI, HI, LO, LO, MED within
3-seconds and the control will display “CLEAR CREDIT?” While still
holding PAUSE press any key to clear credit. Releasing PAUSE
then pressing any key will not clear credit.
Diagnostic Cycle
After selecting DIAGNOSTIC MODE the HI, MED or LOW key is used
to start a dry cycle. The HI is used to increase the dry time. The
MED key will stop the cycle. DEL toggles the HELP SCREEN.
Help Mode
Selecting the HELP MODE displays the HELP SCREEN. In HELP
MODE the HI key will step the highlighted area through all monitored
inputs and provide more detail.
Machine setup is password protected and password is med or
pause key four times.
