The schematic diagram:
In this experiment, by programming the Raspberry Pi, we collect the analog values output
by the Potentiometer module through pin CH0 of the ADC0832, convert it to digital
values and display them on the terminal.
Experimental Procedures
Step 1: Build the circuit
1
2
3
P1
Header
VCC
GND
-
+
A
10K
R1
RPot
VCC
GND
220Ω
R2
LED
VCC
GND
