Lesson 6 Controlling an LED by Hall Sensor
Introduction
Hall 3144 is a Hall switch circuit. When the N pole of a magnet approaches to its print
surface, the switch outputs Low; when the N pole moves away, the switch outputs High.
Components
- 1 * Raspberry Pi
- 1 * GPIO Extension Board
- 1 * 40-Pin GPIO Cable
- 1 * Breadboard
- 1 * Hall Sensor Module
- 1 * LED Module
- 2 * 3-Pin Wires
Experimental Principle
The Fritzing image:
The Physical picture:
Pin definition:
S
Output
+
VCC
-
GND
