Lesson 2 Controlling an LED by Button
Introduction
A button is an electronic switch and usually used for device control.
Components
- 1 * Raspberry Pi
- 1 * GPIO Extension Board
- 1 * 40-Pin GPIO Cable
- 1 * Breadboard
- 1 * Button Module
- 1 * LED Module
- 2 * 3-Pin Wires
Experimental Principle
The Fritzing image:
Pin definition:
S
Output
+
VCC
-
GND
The Physical picture:
The schematic diagram:
