ADEEPT Ultimate Sensor Kit for Raspberry Pi - Page 122

Pin definition:
S
Digital Output
A
Analog Output
+
VCC
-
GND
In this experiment, by programming the Raspberry Pi, we read the analog values collected
by the MQ-2 Gas Sensor and display them on the terminal.
Experimental Procedures
Step 1: Build the circuit
