4.2. Radio channels
The S200 register allows you to choose the desired «channel/transmission rate/RF power» combination:
4.2.1 «Wide band» channels
«Wide band» channels are chosen according to the following table:
ARF53-PRO ARF43-PRO ARF33-PRO
Canal
S200
Frequency
(MHz)
Data rate
(kbps)
Power
(dBm)
Data rate
(kbps)
Power
(dBm)
Data rate
(kbps)
Power
(dBm)
1 869.525 57.6 27/24
(1)
57.6 17 57.6 10
3 868.25 57.6 14 57.6 14 57.6 10
4.2.2 «Narrow band» channels
The 67 «narrow band» channels are chosen according to the following table:
ARF53-PRO ARF43-PRO ARF33-PRO
Canal
S200
Frequency
(MHz)
Data rate
(kbps)
Power
(dBm)
Data rate
(kbps)
Power
(dBm)
Data rate
(kbps)
Power
(dBm)
18 869,55 10 20 10 17 10 10
19 869,45 10 20 10 14 10 10
22 869,15 10 14 10 14 10 10
23 869,05 10 14 10 14 10 10
24 868,95 10 14 10 14 10 10
25 868,85 10 14 10 14 10 10
26 868,75 10 14 10 14 10 10
28 868,55 10 14 10 14 10 10
29 868,45 10 14 10 14 10 10
30 868,35 10 14 10 14 10 10
31 868,25 10 14 10 14 10 10
32 868,15 10 14 10 14 10 10
33 868,05 10 14 10 14 10 10
34 867,95 10 14 10 14 10 10
35 867,85 10 14 10 14 10 10
36 867,75 10 14 10 14 10 10
37 867,65 10 14 10 14 10 10
38 867,55 10 14 10 14 10 10
39 867,45 10 14 10 14 10 10
40 867,35 10 14 10 14 10 10
41 867,25 10 14 10 14 10 10
42 867,15 10 14 10 14 10 10
43 867,05 10 14 10 14 10 10
44 866,95 10 14 10 14 10 10
45 866,85 10 14 10 14 10 10
