Document code: MN67619_ENG Revision 1.000 Page 6 of 25
CHARACTERISTICS:
The HD67619-A1 is a S7comm / PROFIBUS slave Converter.
It allows the following characteristics:
Two-directional information between S7comm and PROFIBUS;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8…24V AC or 12…35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].
CONFIGURATION:
You need Compositor SW67619 software on your PC in order to perform the following:
Define the parameter of the PROFIBUS;
Define the parameter of the S7comm;
Define the S7comm requests to send to the S7comm servers;
Update the device.
