DMX TRAITS
CHANNEL
DMX VALUES FUNCTION
6 CH 7 CH 8 CH 13 CH
1 1 1 1 000 - 255 Red, 0% to 100%
2 2 2 2 000 - 255 Green, 0% to 100%
3 3 3 3 000 - 255 Blue, 0% to 100%
4 4 4 4 000 - 255 White, 0% to 100%
5 5 5 5 000 - 255 Amber, 0% to 100%
6 6 6 6 000 - 255 UV, 0% to 100%
7 7 7 000 - 255 Master Dimmer, 0% to 100%
8 8
Strobe
000 - 031 LED Off
032 - 063 LED On
064 - 095 Strobe, slow to fast
096 - 127 LED On
128 - 159 Strobe Pulse, slow to fast
160 - 191 LED On
192 - 223 Random Strobe
224 - 255 LED On
9 000 - 255
Color Macro, see Color Macro Chart section of
this manual
10
Auto Programs
000 - 019 No Function
020 - 039 Program 1
040 - 059 Program 2
060 - 079 Program 3
080 - 099 Program 4
100 - 119 Program 5
120 - 139 Program 6
140 - 159 Program 7
160 - 179 Program 8
180 - 199 Program 9
200 - 219 Program 10
220 - 239 Program 11
240 - 255 Program 12
11 000 - 255 Auto Program Speed, slow to fast
12 000 - 255 Auto Program Fade, slow to fast
CONTINUED ON NEXT PAGE
