ADJ Products, LLC - www.adj.com - 12PX Hex/12PX Hex Pearl User Manual Page 7
12PX Hex/12PX Hex Pearl Layout
LCD Screen
Mode Button
Up Button
Down Button
Enter Button
Power In Port
Power Out Port
3-Pin XLR Out Port
3-Pin XLR In Port
5-Pin XLR Out Port
5-Pin XLR In Port
