ADJ Products, LLC - www.adj.com - 5PX Hex/5PX Hex Pearl User Manual Page 20
5PX Hex/5PX Hex Pearl Dimensional Drawing
8.18”/207.9mm
8.71”/221.4mm
4.48”/114mm
