ADJ Products, LLC - www.adj.com - 5PX Hex/5PX Hex Pearl User Manual Page 17
5PX Hex/5PX Hex Pearl Operating Instructions
Activate RF Control:
This function is used to activate and deactivate the RF Remote Control. When this function is activated
you can control the fixture using the Dotz Par RF remote. Please see the next page for remote controls
and functions.
1. Plug the fixture in and press the MODE button until “rFXX” is displayed. “XX” represents either
“on” or “oFF”.
2. Press the UP or DOWN buttons to either activate the remote function (On) or deactivate it (Off).
DMX State:
This mode is used as a precaution mode, that in case the DMX signal is lost, the operating mode
chosen in this setup is the running mode the xture will go into when the DMX signal is lost. You can
also set this as the operating mode you would like the unit to return to when power is applied.
1. Press the MODE button until the DMX address is displayed. Press the ENTER button until either
“Soun”, “HOLd”, or “blC” is displayed.
2. Use the UP or DOWN buttons to nd the mode you want incase of power loss or DMX loss.
• “blC” (Blackout) - If the DMX signal is lost or interrupted, the unit will automatically go into stand by
mode.
• “HOLd” (Last State) - If the DMX signal is lost or interrupted, the xture will stay in the last DMX set
up. If power is applied and this mode is set, the unit will automatically go into the last DMX set up.
• “Soun” (Sound Active) - If the DMX signal is lost or interrupted, the unit will automatically go into
sound active mode.
3. Find your desired setting and press ENTER. Your setting will be saved automatically.
5PX Hex/5PX Hex Pearl Master-Slave Configuration
Master-Slave Configuration:
This function will allows you to link units together to run in a Master-Slave mode. In Master-Slave
operation one unit will act as the controlling unit and the others will react to the controlling units
built-in programs. Any unit can act as a Master or as a Slave however, only one unit can be
programmed to act as the “Master.”
Master-Slave Connections and Settings:
1. Daisy chain your units via the XLR connector on the rear of the unit. Use standard XLR data
cables to link your units together. Remember that the Male XLR connector is the
input and the Female XLR connector is the ouput. The first unit in the chain (master) will use the
female XLR connector only. The last unit in the chain will use the male XLR connector only.
2. Set the “Master” unit to your desired mode of operation.
3. Connect the rst “Slave” unit to the “Master.”
4. On the “Slave” unit press the MODE button until “SLAV” is displayed. The “Slave” unit will now
follow the “Master”.
