ADJ LTS-50T - Technical Specifications; General Specifications Summary; Product Dimensions Diagram

15
TECHNICAL SPECIFICATIONS
Total Height Range: 63.8” (1,620 mm) to 128” (3,250 mm)
Recommended maximum height: 128” (3,250 mm.)
Weight capacity: 200 lbs. (90.7 kg)
I-Beam Diameter: 1.50” (38 mm)
System Weight: 45 lbs. (20.4 kg)
DIMENSIONS
Specifications subject to change without any prior written notice.
118.1”
3,000 mm
39.4”
1,200 mm
39.4”
1,200 mm
Ø 70”
Ø 1,778.2 mm
73.3”
1,861.2 mm
188.1”
4,778.2 mm
mm
128”
3,250 mm
