ADJ ZIPPER - 3 Channel Mode DMX Traits; 11 Channel Mode DMX Traits

ADJ Products, LLC - www.adj.com - Zipper Instruction Manual Page 18 ADJ Products, LLC - www.adj.com - Zipper Instruction Manual Page 19
Zipper 11 Channel Mode - DMX Traits & Values
Channel Value Function
1 BARREL 1
0 STOP
1 - 127 CLOCKWISE ROTATION SLOW - FAST
128 - 255 COUNTER-CLOCKWISE ROTATION
FAST - SLOW
2 BARREL 2
0 STOP
1 - 127 CLOCKWISE ROTATION SLOW - FAST
128 - 255 COUNTER-CLOCKWISE ROTATION
FAST - SLOW
3 BARREL 3
0 STOP
1 - 127 CLOCKWISE ROTATION SLOW - FAST
128 - 255 COUNTER-CLOCKWISE ROTATION
FAST - SLOW
4 BARREL 4
0 STOP
1 - 127 CLOCKWISE ROTATION SLOW - FAST
128 - 255 COUNTER-CLOCKWISE ROTATION
FAST - SLOW
5 RED LED
0 - 255 0% - 100%
6 GREEN LED
0 - 255 0% - 100%
7 BLUE LED
0 - 255 0% - 100%
8 WHITE LED
0 - 255 0% - 100%
9 MASTER DIMMER
0 - 255 0% - 100%
10 STROBE
0 - 7 BLACKOUT
8 - 15 OPEN
16 - 131 STROBING SLOW - FAST
132 - 139 OPEN
140 - 181 SLOW OPEN - FAST CLOSE
182 - 189 OPEN
Zipper 3 Channel Mode - DMX Traits & Values
Channel Value Function
1 PAN/TILT MOVEMENTS
0 - 7 0 DEGREES
8 - 22 MOVEMENT 1
23 - 37 MOVEMENT 2
38 - 52 MOVEMENT 3
53 - 67 MOVEMENT 4
68 - 82 MOVEMENT 5
83 - 97 MOVEMENT 6
98 - 112 MOVEMENT 7
113 - 127 MOVEMENT 8
128 - 142 MOVEMENT 9
143 - 157 MOVEMENT 10
158 - 172 MOVEMENT 11
173 - 187 MOVEMENT 12
188 - 202 MOVEMENT 13
203 - 217 MOVEMENT 14
218 - 232 MOVEMENT 15
233 - 247 MOVEMENT 16
248 - 255 SOUND ACTIVE MOVEMENT 1-16
2 DIMMER
0 - 255 0% - 100%
3 STROBING
0 - 7 OFF
8 - 15 OPEN
16 - 131 STROBING SLOW - FAST
132 - 139 OPEN
140 - 181 PULSE EFFECT SLOW - FAST
FAST CLOSE - SLOW OPEN
182 - 189 OPEN
190 - 231 PULSE EFFECT SLOW - FAST
SLOW CLOSE - FAST OPEN
232 - 239 OPEN
240 - 247 SOUND ACTIVE STROBING
2 4 8 - 2 5 5 O P E N
