allows users to filter or cherry pick programs destined for the output from an MPTS input.
Up to 5 services can be mapped to the ASI Filtered output.
ASI TS Source - ASI TS Source configures the transport stream input to ASI output routing
of the IRD.
ASI Output TMR - ASI Output TMR determines the ASI egress rate. When set to AUTO, the
default, the output rate will be the sum of all PIDs configured for the output + minimal NULL
stuffing. When set to NATIVE, the output TMR is set to match the INPUT source TMR.
MANUAL is a user defined rate.
Manual TMR - When ASI Output TMR is set to MANUAL, this field may be configured for a
value in Mb/s.
IP Tx configures IP Destinations and Service Filtering for the IP Outputs. A summary table
of active configuration can be seen when visiting the IP Tx tab. Click edit next to the
desired destination to configure parameters. Read more about protocols in the IP section.
70
