8612 and 8614 Router QSG Logging Into the SDG-8612 and SDG-8614
6SDG861214-13A 5
Logging Into the SDG-8612 and SDG-8614
Using SmartOS
A browser-based graphical user interface (GUI) is used to manually configure the SDG-8612 and SDG-8614. The following steps describe how
to connect and login to the device:
1. Ensure your computer is connected to the SDG-8612 and SDG-8614 either via Wi-Fi or Ethernet connection to one of the LAN ports.
2. Configure your computer’s network interface to acquire an IP address automatically using DHCP.
3. Open a web browser and enter the following: http://router or http://setup. A sign-in page should appear. If you are unable to connect to
the SDG-8612 and SDG-8614 using either of these shortcuts, you can also enter the IP address of the unit. The default IP address is
192.168.1.1.
4. The default username is admin. The password is the account password that was specified during the quick setup.
5. Select Sign In. The Dashboard page appears, showing data about the system.
Product Specifications
Electrical
■ Power is provided by a region specific AC to 15V DC power adapter that is included with the SDG-8612 and SDG-8614. The nominal output
is 15V DC ±5% with a minimum current rating of 3.0 Amps. Regional plug adapter specifications are as follows:
Environment
■ Operating Temperature: 41°F to 104°F (5°C to 40°C)
■ Storage Temperature: -13°F to 158°F (-25°C to 70°C) any humidity
■ Transportation Temperature: -40°F to 158°F (-40°C to 70°C) any humidity
■ Operating Humidity: 5 to 85 percent, relative humidity, non-condensing
Compliance
This product meets the following compliance requirements:
■ UL /cUL Listed
■ FCC Part 15, Class B
■ FCC Part 1l, 2.1091 (MPE)
■ ICES-003 (Class B)
■ ACMA/RCM
■ IEC 62368-1
■ EN 62368-1, AS/NZS 62368.1
■ ErP
■ RoHS Compliant
NOTE
g
If you have forgotten the password for this device, select Forgot password? and follow the instructions to reset the device to the factory
defaults. Next, follow the instructions under “Quick Setup for the SDG-8612 and SDG-8614” on page 4.
Region Power Connector Type Certifications
North America 120VAC @ 60Hz NEMA 1-15 Type A, right-angle orientation cULus Listed
United Kingdom 230VAC @ 50Hz Type G UKCA Listed
EU 220~240VAC @ 50Hz Type C/F CE compliant with NB code, TÜV
Austrailia/New Zealand 220~240VAC @ 50Hz Type I, right-angle orientation RCM Tick Mark, ERAC Listed
CAUTION!
f
It is recommended that an external AC Surge Protection Device be installed at the AC input connection to the local AC-Powered
product. The Surge Protection device should provide L-N, L-G, and N-G protection. It is also recommended that the device contains
a visual 'GOOD' indicator.
