2.1.3 Mx-4400/LE
Earth Lead to
Cover
Chassis Assembly
Loops 1 - 4
Rear Enclosure
Door
Battery Shelf
Loops 1 - 4
Bus-bars for cable earth
connections
Viewing Window
for Loops 1-4
Additional
Battery Shelf
2.1.4 Mx-4800
Earth Lead to
Cover
Chassis Assembly
Loops 1-4
Rear Enclosure
Door
Battery Shelf
Loops 1-4
Bus-bars for cable earth
connections
Viewing Window
for Loops 1-4
Viewing Window
for Loops 5-8
Chassis Assembly
Loops 5-8
Battery Shelf
Loops 5-8
