The definition for each cause is as follows:
Coincidence of 2 or more fire detectors or a single manual call point in the same zone.
Activation of an input device programmed with an ‘Alarm’ action.
A device in a pre-alarm condition.
Any device entering a fault condition.
Whenever an input device is disabled.
A 'Walk Test' fire in the zone.
A control input in this zone will cause activation.
Coincidence Detection.
The operation of the Coincidence Detection (Double Knock) feature is on a per zone
basis.
3.3.8.3 Style
The way in which an output turns on in response to a particular input event can be programmed. For example,
an output may turn on immediately, it may turn on after a delay or it may pulse for a set time and then turn on.
This method of operation is called a Style. A style may have up to three different methods of operation. For
example,
Delay Mode, Wait Mode, Wait Mode.
Style 00 is fixed to turn on immediately an input event occurs.
Style 01 is fixed to pulse immediately an input event occurs.
Styles 02 to 20 are programmable (02 to 10 on Mx-4100).
Press the button to step on to the style field. Change the setting using number entry to select the required
output style. If the style is already programmed elsewhere, the relevant style parameters are automatically
entered into the appropriate fields.
3.3.8.3.1 Delay
The delay field is the time from qualification of the input event to something happening at the output. The delay
time can be set in intervals of 1 second up to a maximum of 250 seconds.
Press the button to step on to the delay field and change the setting using number entry.
3.3.8.3.2 Mode
The mode field defines the method of operation of the output when it is first activated. This can be ON or
PULSE.
Press the button to step on to the delay field and change the setting using the ✔ button.
Note: Pulse settings are by default 1-second ON / 1-second OFF. Other pulse options can be specified on the
PC Tool (such as 2s ON / 3s OFF) – these can be assigned to on-board outputs only.
3.3.8.3.3 Wait
The wait field is the time from first activation of the output to the next operational condition (mode) of the output.
For example, the output could initially be delayed for 20 seconds and turn on in a pulsing mode. After a wait of a
further 30 seconds it can be programmed to turn on differently such as ON. The wait time can be set in intervals
of 1 second up to a maximum of 250 seconds.
Press the button to step on to the wait field and change the setting using number entry.
