/E Enclosures comprises:
Back Box
Door with Display Card mounted onto a
fascia plate. Key-Lock (2).
Option for eight key-switches or four key-
switches and a printer.
Option for MXP-513-XXX LED cards fitted
to door.
The MX-5800 consists of two independent
systems comprising of 4-LP Base Cards
and Display Cards (only one display is
normally visible) and each system capable
of supporting 512 detection devices.
Network cards are fitted as standard and
wired internally. Additional information on
networking is detailed in document 680-
502.
For redundancy of indications and controls,
install an MX-5030 Remote Terminal.
For redundancy of parent functions (i.e.
Fire Alarm Routing, Fire Brigade Terminals,
etc.) install these with redundant
connection from each chassis using the
appropriate interfaces.
