If the number is entered incorrectly, press the ‘Esc’ button to restore the previous number.
3.2 Level 3 Menu Functions
The following table gives a list of the Level 3 Menu Functions, the sub-functions available within each main
function and a brief description for each function. The menu options are available on three pages – select “Next
Menu” to switch between pages.
Main Menu Option
Sub Menus
Comments
3
4
LOOPS
View/Edit
View, test and configure the loop devices.
P
A
G
E
1
Auto Learn
Learn the Devices Present on the Loop.
Calibrate
Calibrates devices on the loop.
History
View historic information (last activation, last test, etc.) of each device.
Meter
View information on the driver circuit performance.
Scope
6
View oscilloscope of driver circuit performance
6
ZONES
--
Configure the Zone texts.
EXIT
--
Cancel Level 3 Access and return to Level 2 Menu Options.
DISABLE
7
Disable Zones/inputs, Outputs and Groups.
ENABLE
7
Enable Zones/Inputs, Outputs and Groups.
VIEW
Fires
View Zones and Inputs that are reporting a fire alarm condition.
Faults
View Zones and Inputs that are reporting a fault condition.
Alarms
View Zones and Inputs that are reporting an alarm condition during test.
Disabled
View Zones, Inputs and Outputs that are disabled.
Inputs
View the current state of Zones and Inputs.
Outputs
View the current operational condition of all output circuits.
Log
View the Event Log.
Panel
View the software of all installed components and the operational state,
voltage & current loading of the panel I/O hardware.
Network
View Network Diagnostics.
Warnings
View Zones and Inputs that are reporting a warning condition
Supervisory
View Zones and Inputs that are reporting a supervisory condition
2
PASSWORDS
--
Configure the Level 2 and Level 3 passwords.
P
A
G
E
2
TIME/DATE
--
Change the Date and Time Settings.
PC-CONFIG
--
Enable the PC Link for transfer of configuration data to and from the panel.
EN54-13
--
Configure the Operating Characteristics of the Output Circuits.
1
SETUP
--
Configure General Operating Parameters.
DISPLAY
--
Adjust the display contrast setting
PANEL
--
View and configure all panel internal circuits.
P
A
G
E
3
5
OUTPUT-GROUPS
--
Configure Output Group Cause and Effect Programming.
TEST
7
Test Zones, Display, Buzzer, Printer and Outputs.
6
Refer to separate application note on this function
7
The operation of these menu functions are not described in this manual – refer to the User Manual for further information.
