2.6 Pager Zones
Each Pager Address must be configured to define
from which zones the events will be sent to the pager.
This can be used to prevent unnecessary or unwanted
events being sent to all pagers or it can be used to define
only those zones that are relevant to a specific person.
For example, a nurse pager can be configured to cover
only those zones concerned with the hospital wards
covered by the nurse.
Up to two ranges can be defined.
Right Click in the table or on a specific address to Add /
Delete / Edit and entry.
A new pop-up dialogue box is shown.
Define the new pager number and address ranges as
required. See example below.
If only one address
range is required,
then use “Zonal Range 1” only.
The maximum zone range is 1 – 2000.
2.7 Upload Communications
To upload the configuration data to the pager interface, first unplug the
cable from the base card and plug in the upload / download lead as
shown opposite.
Click on the “Connect to Target” button and when
communications is established, click on the “Upload” button to transfer the
data.
On completion, remove the upload / download lead and re-fit the lead
from the base card.
