Specifications:
Models, Sales Order Parts:
Mxp-547 Pager Interface Card
Mxp-547-BX Pager Interface (Boxed)
Applications / Limitations:
For use with Pager Systems compliant to ESPA 4.4.4 protocol
If a printer is also required, fit an internal Mxp-512 printer assembly.
Compatibility:
A new PC configuration program (MxPager) is provided for configuring the pager interface.
The interface has been compatibility tested with Multitone pager systems.
The Mxp-547 can be installed on the chassis plate in the medium, large and deep panels.
The Mxp-547-BX can be used with all Mx-5000 Series panels.
Item
Specification Details
Power supply
15-30V DC (e.g. Wired from panel 24V auxiliary supply)
Supply current
50mA (typical at 24V DC).
Temperature
-5°C to 50°C
Humidity
95% Humidity (non condensing)
Dimensions
PCB: 85mm H x 105mm W x 15mm D
Enclosure: 218mm H x 300mm W x 45mm D
Panel Interface
RS232 Galvanically (Opto) isolated
Pager Interface
RS232 Galvanically (Opto) isolated
Fault Input
Non-monitored / Monitored (10K EOL, 470R active)
Maximum № of Pagers
250
Maximum № of Groups
50
Maximum № of Pagers
per Group
8
Event Types Supported
Fire Alarm, Test Alarm, Plant Alarm, Pre-Alarm, Fault, and Disablement
As our policy is one of constant product improvement the right is therefore reserved to modify product specifications without prior notice
