Chapter 3
Chapter 3 I/O Modules 3-53
RL4 NO
RL4 COM
RL3 NO
RL3 COM
Figure 3-50
Form C relay output (ADAM-4068)
Figure 3-51
Form A relay output (ADAM-4068)
RL1 NO
RLO NO
RLO COM
RLO NO
