Advantech ADAM-4571L User Manual

3 Chapter 1
1.3 Specifications
LAN
• Compatibility: IEEE 802.3, IEEE 802.3u
• Speed: 10/100 Mbps, auto-sensing
• No. of Ports: 1
• Port Connector: 8-pin RJ45
• Protection: Built-in 1.5 KV magnetic isolation
Serial Communications
• Port Type: ADAM-4570 series: RS-232/422/485
ADAM-4571L/4570L: RS-232
• No. of Ports: ADAM-4571/4571L: 1
ADAM-4570/4570L: 2
• Port Connector: ADAM-4571/4571L: DB9 male
ADAM-4570/4570L: 10-pin RJ48
• Data Bits: 5, 6, 7, 8
• Stop Bits: 1, 1.5, 2
• Parity Bits: None, Odd, Even, Space, Mark
• Flow Control: XON/XOFF, RTS/CTS, DTR/DSR
• Baud Rate: 50 bps to 921.6 Kbps
• Serial Signals: RS-232: TxD, RxD, CTS, RTS, DTR, DSR, DCD,
RI, GND
RS-422: TxD+, TxD-, RxD+, RxD-, GND
RS-485: Data+, Data-, GND
• Protection: 15 KV ESD protection for all signals
