Advantech ADAM-6224 - B.1.2 Analog Input Command Set

151 ADAM-6200 User Manual
Appendix B ADAM-6200 ASCII Commands
B.1.2 Analog Input Command Set
Function Description Command Example
Read analog
input from Chan-
nel N
Return the input value
from the specified ana-
log input channel
Cmd: #aan(cr)
Ret:>+nnnn.nnn(cr)
or >–nnnn.nnn(cr)
Send: #010(cr)
Receive:
>+0000.000(cr)
Read analog
input from all
channels
Returns the input data
from all analog input
channels in a specified
module.
Cmd: #aa(cr)
Ret:>(data) (data)
(data) (data) (data)
(data) (data) (data)(cr)
Where (data) is
+nnnn.nnn
or –nnnn.nnn
Send: #010(cr)
Receive:
>+0010.000+0010.000
+0010.000+0010.000+
0010.000+0010.000+0
010.000+0010.000(cr)
Auto Calibration
Calibrate the analog
input range of module
Cmd: $aa1(cr)
Ret:!aa(cr)
Send: $011(cr)
Receive: !01(cr)
Read channel
Enable/Disable
Status
Asks a specified module
to return the Enable/Dis-
able status of all analog
input channels
Cmd: $aa6(cr)
Ret:!aamm(cr)
Send: $016(cr)
Receive: !01FF(cr)
Set channel
Enable/Disable
Status
Set Enable/Disable sta-
tus for analog input chan-
nels
Cmd: $aa5mm(cr)
Ret:!aa(cr)
Send: $015FF(cr)
Receive: !01(cr)
Read all Max.
Data
Read the maximum data
from all analog input
channels
Cmd: #aaMH(cr)
Ret:> (data) (data)
(data) (data) (data)
(data) (data) (data)(cr)
Where (data) is
+nnnn.nnn
or –nnnn.nnn
Send: #01MH(cr)
Receive:
>+0010.000+0010.000
+0010.000+0010.000+
0010.000+0010.000+0
010.000+0010.000(cr)
Read single Max.
Data
Read the maximum date
from a specified analog
input channel
Cmd: #aaMHn(cr)
Ret:> (data) (cr)
Where (data) is
+nnnn.nnn
or –nnnn.nnn
Send: #01MH1(cr)
Receive:
>+0010.000(cr)
Read all Min.
Data
Read the minimum data
from all analog input
channels
Cmd: #aaML(cr)
Ret:> (data) (data)
(data) (data) (data)
(data) (data) (data)(cr)
Where (data) is
+nnnn.nnn
or –nnnn.nnn
Send: #01ML(cr)
Receive:
>+0000.000+0000.000
+0000.000+0000.000+
0000.000+0000.000+0
000.000+0000.000(cr)
Read single Min.
Data
Read the minimum data
from a specified analog
input channel
Cmd: #aaMLn(cr)
Ret:> (data) (cr)
Send: #01ML3(cr)
Receive:
>+0000.000(cr)
Read Analog
input range code
Return the input range
code from the specific
analog input channel
Cmd: $aaBnn(cr)(cr)
Ret:> aa(Code) (cr)
Send: $01B01(cr)
Receive: >010182(cr)
