Advantech DS-085 Series User Manual

DS-085
Series User Manual
24
2.2.8 DIO Connector
DS-085 Series provides one D-sub 9-pin connectors. The ports support DI/DO/Power On &
Off communications.
Figure 2.10：DIO Connector
COM Port Pin Assignments
Pin
1 GND
2 GPIO_2
3 GPIO_1
4 PS IN(Power switch)
5
6
7
8
9
2.2.9 IR Phone Jack
DS-085 Series provides 3.5mm phone jack to connect with IR receiver for remote controller
possibility.
Figure 2.11：IR Phone Jack
