Advantech ICR-3241 - Type Tests and Environmental Conditions

ICR-3241
4.3 Type Tests and Environmental Conditions
Phenomena Test Description Test levels
ESD EN 61000-4-2 Enclosure contact
Enclosure air
± 6 kV (crit. A)
± 8 kV (crit. A)
RF field AM
modulated
EN 61000-4-3 Enclosure 20 V/m (crit. A)
(80 – 10000 MHz)
10 V/m (crit. A)
(1 – 6 GHz)
Fast transient EN 61000-4-4 Signal ports
Power ports
Ethernet ports
± 1 kV (crit. A)
± 2 kV (crit. A)
± 1 kV (crit. A)
Surge EN 61000-4-5 Ethernet ports
Power ports
± 1 kV (crit. A), shielded cab.
± 2 kV (crit. A)
RF conducted EN 61000-4-6 All ports 10 V/m (crit. A)
(0,15 – 80 MHz)
Radiated emission EN 55032 Enclosure Class B
Conducted
emission
EN 55032 DC power ports
Ethernet ports
Class B
Class B
Dry heat EN 60068-2-2
MIL-STD-810G
SAE J1455
+75
◦
C *, 40 % rel. humidity
Cold EN 60068-2-1
MIL-STD-810G
SAE J1455
-40
◦
C *
Damp heat EN 60068-2-78
MIL-STD-810G
SAE J1455
95 % rel. humidity (+40
◦
C)
Vibration EN 60068-2-64 ed. 2
MIL-STD-810G
SAE J1455
Vibration spectrum
A.3 (rolling stock)
Category 1 (3 axis, 8 hours
per axis)
Shock EN 60068-2-27 ed. 2
MIL-STD-810G
SAE J1455
half-sine, 50 g peak, 11 ms
Table 14: Type tests and environmental conditions
26
