User Manual
MIO-5251
Intel
®
Celeron
®
J1900 & Atom
™
E3825,
3.5" MI/O-Comp
a
ct SBC, DDR3L,
VGA, HDMI/DP
, 48-bit L
VDS/eDP
,
2GbE, Mini PCIe, mSA
T
A/SD card,
iManager
, MIOe
1
3
Table of Contents
Main Page
Default Chapter
5
Declaration of Conformity
5
Optional Accessories
6
Packing List
6
Chapter 1 General Information
10
Introduction
11
OS Support
13
Block Diagram
14
Figure 1.2 MIO-5251 Mechanical Drawing (Bottom Side)
15
Chapter 2 Installation
16
Jumpers & Switches
17
Locating Connectors
18
Setting Jumpers
19
Clear CMOS (SW2)
20
Chapter 3 AMI BIOS Setup
22
Entering Setup
24
Advanced BIOS Features Setup
25
Chipset Configuration
38
Security
45
Boot
46
Save & Exit
47
Chapter 4 Mioe Installation
48
Quick Installation Guide
49
A.1 Jumper List
51
A.2 Connector Pin Definition
52
System Assignments
72
System I/O Ports
73
Interrupt Assignments
74
EC Watchdog Timer Sample Code
77
