PCM-3365 User Manual 58
PA13 FRAME#
PA14 GND
PA15 AD18
PA16 AD21
PA17 +3.3V
PA18 IDSEL0
PA19 AD24
PA20 GND
PA21 AD29
PA22 +5V
PA23 REQ0#
PA24 GND
PA25 GNT1#
PA26 +5V
PA27 CLK2
PA28 GND
PA29 +12V
PA30 -12V
PB1 NC
PB2 AD02
PB3 GND
PB4 AD07
PB5 AD09
PB6 VI/O (+5V or +3.3V)
PB7 AD13
PB8 C/BE1#
PB9 GND
PB10 PERR#
PB11 +3.3V
PB12 TRDY#
PB13 GND
PB14 AD16
PB15 +3.3V
PB16 AD20
PB17 AD23
PB18 GND
PB19 C/BE3#
PB20 AD26
PB21 +5V
PB22 AD30
PB23 GND
PB24 REQ2#
PB25 VI/O (+5V or +3.3V)
PB26 CLK0
PB27 +5V
PB28 INTD#
PB29 INTA#
PB30 REQ3#
