UTC-320 User Manual 4
1.3 LCD Specifications
Display type: 21.5" TFT LCD
Max. resolution: 1920 x 1080
Colors: 16.7 M
Pixel Pitch (um): 248.25 (H) x 248.25 (V)
View Angle: 89°/89°
Luminance: 200 cd/m
2
1.4 Optional modules
Memory: 1 x SO-DIMM DDR3L 1333 MHz up to 8 GB
HDD: 2.5" SATA HDD
Operating System: Windows Embedded Standard 7, Windows Embedded
Standard 8.1, Embedded Linux 3.0, Windows Embedded Standard 10
Touchscreen: Analog resistive (Optional - PCT solution)
Power cord: 1702002600 (US) 1702002605 (Europe)
Wireless LAN Module:
Note! The color LCD display installed in the UTC-320 is high-quality and reli-
able. However, it may contain a few defective pixels which do not
always illuminate. With current technology, it is impossible to completely
eliminate defective pixels. Advantech is actively working to improve this
technology.
Part No. Description
968EMW0071 Wireless 802.11abgn AR9382 2T2R Full-size DNXA-1
1750006682-01 Main antenna wireless 200 mm
