23 UTC-320 User Manual
Chapter 4 Jumper Settings and Connectors
4.2 Jumpers
4.2.1 Jumper List
4.2.2 Jumper Settings
Table 4.2: Jumper List
JP1 LCD PWM POWER
JP2 LCD ENABLE POWER
JP3 LCD POWER
JP4 TOUCH POWER
JP5 AT/ATX POWER SEL
JP6 Clear CMOS
CN9 COM1/COM2 RING POWER
CN10 CSAFE POWER
Table 4.3: JP1:LCD PWM POWER
Part Number 1653003101
Footprint HD_3x1P_79_D
Description PIN HEADER 3x1P 2.0mm 180D(M) DIP 2000-13 WS
Setting Function
(1-2) 5V
(2-3)* 3.3V
Table 4.4: JP2:LCD ENABLE POWER
Part Number 1653003101
Footprint HD_3x1P_79_D
Description PIN HEADER 3x1P 2.0mm 180D(M) DIP 2000-13 WS
Setting Function
(1-2) 5V
(2-3)* 3.3V
