UTC-320 User Manual
16
3.4
Inst
alling the WLAN
Reserve two locations for the external Antenna.
One is at the IO port, the other is at
the rear cover
. Customers can choose based on their requirement.
1.
Remove 12 x screws from the back cover
.
2.
Remove 6 screws on the reinforced board.
3.
Coaxial cable (Advant
ech P/N: 1750006682-01)
