UTC-320 User Manual 24

Table 4.5: JP3:LCD POWER

Part Number 1653003100

Footprint HD_3x1P_100_D

Description PIN HEADER 3x1P 2.54mm 180D(M) DIP 1130-000-03S

Setting Function

(1-2) 5V

(2-3)* 3.3V

Table 4.6: JP4: TOUCH POWER

Part Number 1653003101

Footprint HD_3x1P_79_D

Description PIN HEADER 3x1P 2.0mm 180D(M) DIP 2000-13 WS

Setting Function

(1-2)* +3.3V

(2-3) +3.3VSB

Table 4.7: JP5: AT/ATX POWER SEL

Part Number 1653005101

Footprint HD_5x1P_79_D

Description PIN HEADER 3x1P 2.0mm 180D(M) DIP 2000-13 WS

Setting Function

(1-2) AT

(2-3)* ATX
