UTC-320 User Manual 36

Table A.10: CN11:CSAFE

Part Number 1655000197

Footprint WF_5x2P_79_BOX_D_P1R

Description 1655_WF_5x2P_79_BOX_D_P1R_0.Normal

Pin Pin name

1 LINE_IN1_L

2 LINIE_IN1_R

3COM3_ RX+

4COM3_TX

5 V_CSAFE

6COM3_CTS#

7GND

8GND

9
