39 UTC-320 User Manual

Appendix A I/O Pin Assignments

Table A.14: CN21: Line-out

Part Number 1652001586

Footprint KUONYI_PJ-2508PC-5-L

Description PHONE JACK 5P 3.5φ 90D(F) AZALIA GREEN DIP WO/P

Pin Pin name

1GND

2OUT_L

3JD

4OUT_R

5GND

Table A.15: CN22: MIC-IN

Part Number 1652001584

Footprint KUONYI_PJ-2508PA-5-L

Description PHONE JACK 5P 3.5φ 90D(F) AZALIA PINK DIP WO/Pb

Pin Pin name

1GND

2MIC_L

3JD

4MIC_R

5GND

Table A.16: CN17: LAN1/LAN2

Part Number 1652003274

Footprint RJ45_28P_RTB-19GB9J1A

Description PHONE JACK RJ45 28P DIP RTB-19GB9J1A

Pin Pin name
