Advent ADV10A Installation Guide

MATERIALS INCLUDED IN THIS PACKAGE:
1) 10.1” TFT LCD Overhead Monitor With DVD Player - (1 pc)
2) Hardware Package (P/N 150-1661) - (1 pc)
- M3 x 8mm Phillips Screws (P/N 100-2427) - (5 pcs)
- #4 x 5/16" Phillips Self Tapping Screws (P/N 100-2316) - (1 pc)
- #4 x 7/16" Phillips Self Tapping Screws (P/N 100-2426) - (3 pcs)
- #8 x 3/8" Self Drilling Screws (P/N 100-2397) - (4 pcs)
- M5 x 10mm Phillips Screws (P/N 100-2394) - (4 pcs)
3) Remote Control (P/N 136-4840) - (1 pc)
4) Universal Mounting Bracket (P/N 108-3921) - (1 pc)
5) Dome Light Extension Harness (P/N 112-3884) - (1 pc)
6) 2 Pin Power Harness (P/N 112-4152) - (1 pc)
7) Pry Tool (P/N 100-2424) - (1 pc)
8) Screw Cap - Shale (P/N 102-4253) - (2 pcs)
- Pewter (P/N 102-4232) - (2 pcs)
9) Trim Ring - Shale (P/N 102-4231) - (1 pc)
- Pewter (P/N 102-4232) - (1 pc)
10) Snap On Cover (Screen Back) - Shale (P/N 102-4233) - (1 pc)
- Pewter (P/N 102-4234) - (1 pc)
11) Snap On Cover (Shroud) - Shale (P/N 102-4235) - (1 pc)
- Pewter (P/N 102-4236) - (1 pc)
12) Wireless Headphones (P/N 136-4944) - (2 pcs)
TOOLS REQUIRED:
#2 Phillips Screwdriver
#1 Phillips Screwdriver
Utility or Razor Knife or Shears
Wire Strippers
Upholstery hook tool (for removal of panels as necessary)
Electrical Tape
Masking Tape
Multimeter (to verify 12 volt DC and continuity: Do not use a test light or logic probe)
Marker pen – to mark headliner
Scribe (to mark trim ring if used)
Misc. electrical connectors (to connect to vehicle power source). Requirements will vary from vehicle to
vehicle)
DVD Movie (to verify system operation after installation)
