7
CONTROLS AND INDICATORS DIAGRAM FRONT VIEW
1. HOME ( ) Button
This button is used to display the Home Menu Screen.
2. POWER ( ) Button
This button is used to turn the system on/o.
3. EJECT (
) Button
This button is used for ejecting a disc from the built-in DVD player.
4. Dome Lights
Provide additional interior illumination.
5. Ventilation Openings
6. Screen Release
Push this button to release the screen from the locked position.
7. LCD Backlight Cut O Switch
Used to turn o the LCD backlight when the LCD is in the closed
position.
8. LCD Panel
