6
when equipped with a microphone the audio will be heard on the speaker built into the
mirror housing.
7. Follow the installation and wiring instructions for the camera you are
using.
8. Connect the LCDM40 Monitor to the harness.
9. Power up and adjust on screen settings. In order to see an image you
must be in Reverse gear.
NOTE: To adjust monitor settings press the MENU button on the bottom of the mirror to
scroll through options. Use the + and – buttons to make adjustments as needed.
Arm Adaptor
Note: Used for installation in certain Toyota and Honda vehicles.
If your vehicle has this
mount on the windscreen:
Then use this mounting
block:
Following this installation procedure:
