Monitor Wiring Diagram

Note: If used with an Advent camera – the power and signal will be

provided through a single cable from the monitor.

Red - +12 Volts

Blue – Data In (Not Used)

Black – Ground -12 Volts

Purple – Secondary Trigger +12 Volts

Orange – Reverse Trigger +12 Volts
