BATTERY OVER
TEMPERATURE
The controller can detect the battery temperature through an
external temperature sensor if fitted. The controller stops working
when its temperature exceeds 65 °C and restart to work when its
temperature is below 55 °C. NOTE: With an ambient temperature
sensor fitted, the unit will only stop charging if ambient
temperature exceeds 65°C
LITHIUM
BATTERY LOW
TEMPERATURE
When the temperature detected by the ambient temperature
sensor is lower than the Low Temperature Protection Threshold
(LTPT), the controller will stop charging and discharging
automatically. When the detected temperature is higher than the
LTPT, the controller will work automatically (The LTPT is 0 °C by
default and can be set within the range of 10°C ~ -40 °C).
LOAD SHORT
CIRCUIT
When the load is short circuited (The short circuit current is
≥ 4 times the rated controller load current), the controller will
automatically cut off the output. If the load reconnects the output
automatically five times (delay of 5s, 10s, 15s, 20s, 25s), it
needs to be cleared by pressing the Load button, restarting the
controller or switching from Night the Day (night time > 3 hours).
LOAD
OVERLOAD
When the load is overloading (The overload current is ≥ 1.05
times the rated load current), the controller will automatically cut
off the output. If the load reconnects automatically five times
(delay of 5s, 10s, 15s, 20s, 25s), it needs to be cleared by
pressing the Load button, restarting the controller or switching
from Night to Day (night time > 3 hours).
CONTROLLER
OVER
TEMPERATURE
The controller is able to detect the temperature inside the battery.
The controller stops working when its temperature exceeds 85 °C
and restart to work when its temperature is below 75 °C.
When the internal temperature is >81°C the unit will enter reduced
charging power mode which reduces the charging power by
5%, 10%, 20% and 40% for every increase of 1°C. If the internal
temperature exceeds 85°, the controller will stop charging. When
the temperature declines to below 75°C, the controller will resume
charging.
TVS HIGH
VOLTAGE
TRANSIENTS
The internal circuitry of the controller is designed with Transient
Voltage Suppressors (TVS) which can only protect against high-
voltage surge pulses with less energy. If the controller is to be
used in an area with frequent lightning strikes, it is recommended
to install an external surge arrester.

Adventure Kings PLUS AKPSR-MPPT 01 Specifications

General

SKU	AKPSR-MPPT_01
NAME	20A MPPT Solar Charge Controller / Regulator
System Nominal Voltage	12/24VDC (auto detect except for lithium)
Rated Charge Current	20A
Rated Discharge Current	20A
Max PV Open Circuit Voltage @25°C Standard Test Conditions	46V
MPP Voltage Range	Battery Voltage +2V ~ 36V
Rated Charge Power (12V System)	260W
Rated Charge Power (24V System)	520W
Maximum Solar Input (12V System)	390W
Maximum Solar Input (24V System)	780W
Self-consumption (12V System)	≤14mA
Self-consumption (24V System)	≤15mA
Discharge Circuit Voltage Drop	≤0.23V
Load Circuit	Manual on/off + programmable settings
Grounding	Common negative
Battery Voltage Range	8~32V
*Temperature Compensation for lithium	NO
Selectable 12/24V Battery Types	Sealed, Gel, Flooded, LiFePO4, Li(NiCoMn)O2, User Adjustable
Max Conversion Efficiency	98.3%
Efficiency at full load	96.7%
Temperature Compensation Coefficient*	-3mV/°C/2V
Working Temperature (100% input/ output)	-25°C ~ +50°C
Relative Humidity	≤95% non-condensing
IP Rating	IP33 Dust and Water Resistant
RS485 Interface	5VDC/200mA (RJ45)
Wire Terminal Type and Size	Screw Terminals, Up to 6AWG (16mm2)
Wire Type	100mm length Double Insulated XLPO 6mm2
Plug Type	Quick connect plugs
LCD Backlight time	60 seconds

Weight and Dimensions

Dimensions	217 x 158 x 56.5 mm
Weight	0.96kg
Mounting Hole Spacing	160 x 149 mm
Mounting Hole Dimensions	5mm diameter
