7. Once the wire is securely in the metal terminal block, tighten the screw firmly
8. Repeat for both the battery positive and negative terminals (with one quick
connect plug) and the solar + and – terminals with the other quick connect plug
9. Confirm the polarity of the Solar input plug is connect
10. Confirm the polarity of the Battery plug is correct
11. When mounting the charge controller use screws or bolts, nuts and washers to
ensure it is secure and cannot move or shake loose
12. Allow for 150mm of free space above and below the heat sink
13. Do not mount the Charge Controller on any surface that will be or could be
affected by high temperatures
5. SOLAR ARRAY REQUIREMENTS
The Adventure Kings Plus MPPT Charge Controller has an in-built charging current/
power-limiting function. During the charging process, when the charging current or
power exceeds the rated charging current or power, the controller will automatically limit
the charging current or power to the rated range.
This function protects the controller and prevents damage to the controller due to the
connection of some over-powered PV modules. The actual operation of PV array is as follows:
If charging current or power of the solar panel(s) is less than or equal to the rated
charging current or power of controller it will carry out the charging as per the actual
current or power available at the time. At this time, the controller can work at the
Maximum Power Point of the solar panel(s).
WARNING
Even if the solar panel power is less than the rated charging power, if the
maximum open-circuit voltage of the solar panel exceeds 60V (at the lowest
environmental temperature), the controller may be damaged.
If charging current or power of PV array is greater than the rated charging current or
power of controller, it will charge at the maximum rated current (20A) or power (260W on
a 12V system).
Model Rated Charge
Current
Rated Charge
Power
Max. Solar
Panel Power
Max. Solar
Panel Open
Circuit Voltage
(OCV)
AKPSR-MPPT_01 20A 260W/12V 390W/12V 46V*
520W/24V 780W/24V
*Maximum Open Circuit Voltage of 46V @ 25°C Standard Test Condition Rating

Adventure Kings PLUS AKPSR-MPPT 01 Specifications

General

SKU	AKPSR-MPPT_01
NAME	20A MPPT Solar Charge Controller / Regulator
System Nominal Voltage	12/24VDC (auto detect except for lithium)
Rated Charge Current	20A
Rated Discharge Current	20A
Max PV Open Circuit Voltage @25°C Standard Test Conditions	46V
MPP Voltage Range	Battery Voltage +2V ~ 36V
Rated Charge Power (12V System)	260W
Rated Charge Power (24V System)	520W
Maximum Solar Input (12V System)	390W
Maximum Solar Input (24V System)	780W
Self-consumption (12V System)	≤14mA
Self-consumption (24V System)	≤15mA
Discharge Circuit Voltage Drop	≤0.23V
Load Circuit	Manual on/off + programmable settings
Grounding	Common negative
Battery Voltage Range	8~32V
*Temperature Compensation for lithium	NO
Selectable 12/24V Battery Types	Sealed, Gel, Flooded, LiFePO4, Li(NiCoMn)O2, User Adjustable
Max Conversion Efficiency	98.3%
Efficiency at full load	96.7%
Temperature Compensation Coefficient*	-3mV/°C/2V
Working Temperature (100% input/ output)	-25°C ~ +50°C
Relative Humidity	≤95% non-condensing
IP Rating	IP33 Dust and Water Resistant
RS485 Interface	5VDC/200mA (RJ45)
Wire Terminal Type and Size	Screw Terminals, Up to 6AWG (16mm2)
Wire Type	100mm length Double Insulated XLPO 6mm2
Plug Type	Quick connect plugs
LCD Backlight time	60 seconds

Weight and Dimensions

Dimensions	217 x 158 x 56.5 mm
Weight	0.96kg
Mounting Hole Spacing	160 x 149 mm
Mounting Hole Dimensions	5mm diameter
