Adventure Kings PLUS AKPSR-MPPT 01 User Manual

19
V1.7
FAULT
POSSIBLE
REASON
TROUBLESHOOTING
Solar Indicator LED Green Light +
Battery LED Indicator Orange Light,
BOTH Fast Flashing
Controller
Overheating
When heat sink of
controller Exceeds
85°C the controller will
automatically cut off input
and output circuit. When
the temperature drops
below 75°C, the controller
will resume working.
System Voltage
Error
1. Check whether the
battery voltage matches
with the controller working
voltage.
2. Please change to a
suitable battery or reset the
working voltage.
Load and Fault Icon Blinking
Load Overload
1. Please reduce the power
or number of connected
loads then restart the
controller:
2. By disconnecting from
the battery, waiting 30
seconds and reconnecting
3. Or, wait for one night/day
cycle (night time > 3 hours)
Load Short
Circuit
1. Check the load
connections carefully then
restart the controller:
2. By disconnecting from
the battery, waiting 30
seconds and reconnecting
3. Or, wait for one night/day
cycle (night time > 3 hours)

Adventure Kings PLUS AKPSR-MPPT 01 Specifications

General

SKU	AKPSR-MPPT_01
NAME	20A MPPT Solar Charge Controller / Regulator
System Nominal Voltage	12/24VDC (auto detect except for lithium)
Rated Charge Current	20A
Rated Discharge Current	20A
Max PV Open Circuit Voltage @25°C Standard Test Conditions	46V
MPP Voltage Range	Battery Voltage +2V ~ 36V
Rated Charge Power (12V System)	260W
Rated Charge Power (24V System)	520W
Maximum Solar Input (12V System)	390W
Maximum Solar Input (24V System)	780W
Self-consumption (12V System)	≤14mA
Self-consumption (24V System)	≤15mA
Discharge Circuit Voltage Drop	≤0.23V
Load Circuit	Manual on/off + programmable settings
Grounding	Common negative
Battery Voltage Range	8~32V
*Temperature Compensation for lithium	NO
Selectable 12/24V Battery Types	Sealed, Gel, Flooded, LiFePO4, Li(NiCoMn)O2, User Adjustable
Max Conversion Efficiency	98.3%
Efficiency at full load	96.7%
Temperature Compensation Coefficient*	-3mV/°C/2V
Working Temperature (100% input/ output)	-25°C ~ +50°C
Relative Humidity	≤95% non-condensing
IP Rating	IP33 Dust and Water Resistant
RS485 Interface	5VDC/200mA (RJ45)
Wire Terminal Type and Size	Screw Terminals, Up to 6AWG (16mm2)
Wire Type	100mm length Double Insulated XLPO 6mm2
Plug Type	Quick connect plugs
LCD Backlight time	60 seconds

Weight and Dimensions

Dimensions	217 x 158 x 56.5 mm
Weight	0.96kg
Mounting Hole Spacing	160 x 149 mm
Mounting Hole Dimensions	5mm diameter
