Advice 45 - System Description; Front panel; Back Panel

3
1. System Description
Front panel:
1. Power Switch
2. UPS status Indicator –
AC Mode: Green lighting
Battery Mode: Green flashing
3. Fault LED: Red flashing
Back Panel
1. Output receptacles
H105
2. AC Input with AC fuse
H45 / H55 / H65 / H70
1
2
