6. Specifications
Model TOPV1000 TOPV1500 TOPV2000 TOPV3000
CAPACITY* 1000 VA / 800 W
INPUT
Low Line Transfer
160 VAC / 140 VAC / 120 VAC / 110 VAC ± 5 %
( based on load percentage 100% - 80 % / 80 % - 70 % / 70 - 60 % / 60 % -
Low Line Comeback 175 VAC ± 5 %
High Line Transfer 300 VAC ± 5 %
Voltage
Range
High Line Comeback 290 VAC ± 5 %
Frequency Range 40Hz ~ 70 Hz
Phase Single phase with ground
Power Factor
0.95
OUTPUT
Output voltage 208/220/230/240VAC
AC Voltage Regulation
(Batt. Mode)
± 3%
Frequency Range
(Synchronized Range)
47.5 ~ 52.5 Hz or 57 ~ 63 Hz
Frequency Range (Batt. Mode) 50 Hz ± 0.25 Hz or 60Hz ± 0.3 Hz
Overload
100%~110%: warning
110%-130%: sounding every 12 seconds
>130% : sounding every 1.5 seconds
Current Crest Ratio 3:1
Harmonic Distortion
6 % THD (Non-linear Load)
7 % THD (Non-linear Load)
AC Mode to Batt. Mode
Zero
Transfer
Time
Inverter to Bypass 4 ms (Typical)
Waveform (Batt. Mode) Pure Sinewave
EFFICIENCY
AC Mode ~ 85% ~ 88%
Battery Mode ~ 83%
BATTERY
Battery Type 12 V / 7 AH 12 V / 9 AH 12 V / 7 AH 12 V / 9 AH
Numbers 3 3 6 6
Recharge Time 4 hours recover to 90% capacity (Typical)
Charging Current 1.0 A(max.)
Standard
Model
Charging Voltage 41.0 VDC ± 1% 82.1 VDC ±1%
Battery Type &
Numbers
Depending on the capacity of external batteries
Charging Current 4.0 A or 8.0 A(max.)
Long-run
Model
Charging Voltage 41.0 VDC ± 1% 82.1 VDC ±1%
PHYSICAL
Dimension, D X W X H
397 X 145 X 220 (mm) 421 X 190 X 318 (mm) Tower
Case
Net Weight (kgs) 13 7 14 7 26 13 28 13
Dimension, D X W X H
420x438x88[2U] (mm) 580x438x133[3U] (mm) Rack
Case
Net Weight (kgs) 16 10 17 10 29 17 31 17
ENVIRONMENT
Operation Humidity 20-90 % RH @ 0- 40°C (non-condensing)
Noise Level Less than 45dBA @ 1 Meter
MANAGEMENT
Smart RS-232 or USB Supports Windows 98 SE/ME/NT 4.x/2000/2003/XP/Vista/2008
Optional SNMP Power management from SNMP manager and web browser
• Derate capacity to 60% of capacity in Frequency converter mode and to 80% when the output voltage is
adjusted to 208VAC.
