Advice TOPV 3000 - Installation and setup; Rear panel view; Setup the UPS

4
1000VA(L) 2000VA(L) TOWER 3000VA(L) TOWER
IEC Type
1000VA(L) / 1500VA(L)
RACKMOUNT
2000VA(L) RACKMOUNT 3000VA(L) RACKMOUNT
IEC Type IEC Type IEC Type
Programmable outlets: connect to non-critical loads.
1. Output receptacles: connect to mission-critical loads.
2. AC input
3. Input circuit breaker
4. Network/Fax/Modem surge protection
5. Emergency power off function connector (EPO)
6. USB communication port
7. RS-232 communication port
8. SNMP intelligent slot
9. External battery connection (only available for L model)
10. Output terminal
11. Output circuit breaker
12. Input terminal
