the lens causing reflection.
● The foam ring around the lens must be seated flush against the
inner surface of the bubble to isolate the lens from the IR LEDS.
Fasten the dome cover to camera body so that the foam ring
and the dome cover are attached seamlessly.
Ceiling Mounting 2.1
Steps:
1. Use the supplied drill template as a guide when drilling holes for
the screws and cable.
Type I Drill Template Figure 2-1
